φ0.35 Screen 1480rpm U - Type Grinding Powder Feed Hammer Mill With Nylon Rod Coupler

φ0.35 Screen 1480rpm U - Type Grinding Powder Feed Hammer Mill With Nylon Rod Coupler

large.img.alt
small.img.alt small.img.alt

Large Image :  φ0.35 Screen 1480rpm U - Type Grinding Powder Feed Hammer Mill With Nylon Rod Coupler Get Best Price

Product Details:
Place of Origin: China
Brand Name: Huamu
Certification: ISO ,PRODUCE LINCESE
Model Number: SWSP63X65
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: 4500USD/SET
Packaging Details: Packed in bulk or plywood case
Delivery Time: 20DAYS
Payment Terms: TT,LC,Western union
Supply Ability: 30sets per months
Detailed Product Description
High Light:

mill grinder machine

,

feed hammer mill



φ0.35 Screen 1480rpm U - Type Grinding Powder Feed Hammer Mill With Nylon Rod Coupler



Descrition:

It can perform minute grinding using φ0.35 screen, which is leading in China.

1. The grinding room achieves a real drop-type; an unique air intake way to prevent circulation during the grinding process; a “U-type” secondary beating groove is set up at the bottom of the grinding room to greatly increase the output; a quick full-wide operation door and an elastic pressing screen; convenient to repair and exchange the screen.
2. It adopts import bearings to ensure the life-span; the nylon rod type coupler directly transmits; big compensating displacement to effectively prevent the bearings from getting hot.
3. The rotor, through precise dynamic balance detection, ensures steadier running, lower noise and better properties.
4. The feed port is on the top of the grinder and can be matched with various feeding structures.
5. Through adjustment, it can serve many purposes, e.g., to perform crude grinding, minute grinding and micro-minute grinding.
6. It is applied to high-end livestock and poultry, aquatic feed, and alcohol plants and lemon plants.



φ0.35 Screen 1480rpm U - Type Grinding Powder Feed Hammer Mill With Nylon Rod Coupler 0

Competitive Advantage:

Compared with old style hammer mill ,this is improved ,the capacity is much higher than old style .and the size can get Diameter is 0.35mm.Its hammers can working in two oppsite side.it's suitable for producing high quality of poultry feed pellt .



Specifications:

model and specification

SWSP63x45

SWSP63x65

SWSP112x45

SWSP138x65

Distribution power(KW)

37

45

55

75

90

110

132

160

Feed motor power(KW)

0.75

1.5

1.5

1.5

      output(t/h)

6.0

7.0

9.0

12

16

18

21

26

      Dia of Rotor(mm)

630

630

630

630

1120

1120

1380

1380

      Speed of Rotor(rpm)

2950

2950

1480

1480

1480

1480

1480

1480

    Width of grinding chamber(mm)

450

450

650

650

450

450

450

450



Applications:

It can grind corn ,wheat ,soybean and other grain into powder.It Is applied to high -end livestock and poultry ,aquatic feed ,alcohol plwants and lemon plants .
